LJ60
LEARJET Learjet 60
LEARJET Learjet 60
Aircraft
Name
Learjet 60
Manufacturer
Body
Narrow
Wing
Fixed Wing
Position
Low wing (winglets)
Tail
T-tail
WTC
M
APC
C
Type Code
L2J
Engine
Jet
Engine Count
Multi
Position
Both sides of rear fuselage
Landing gear
Tricycle retractable
Manufactured as
LEARJET 60
Cite This Page
SKYbrary Aviation Safety. (September 2, 2021). LJ60.
Retrieved June 4, 2026
from https://skybrary.aero/aircraft/lj60
UID: 17938
Copied!
COPY
LJ60
Mid-size corporate jet. In service since 1993. Modified version of Learjet 55 with stretched fuselage and more powerful Pratt&Whitney engines. Largest member of Learjet family.
The LJ60 is a member of the Bombardier Learjet Family.
Technical Data
Wing span (metric)
13.40 m
Length (metric)
17.90 m
Height (metric)
4.50 m
Powerplant
2 x 20.46 kN PWC PW 305 A turbofans.
Engine Model(s)
Pratt & Whitney Canada PW300
Indicative Performance Data
Take-Off
V2
n/a
Distance
1661 m
MTOW
10659 kg
Initial Climb (to 5000 ft)
IAS
300 kts
ROC
4500 ft/min
Initial Climb (to FL150)
IAS
330 kts
ROC
n/a
Initial Climb (to FL240)
IAS
330 kts
ROC
n/a
MACH Climb
MACH
0.81
ROC
n/a
Cruise
TAS
453 kts
MACH
0.81
Ceiling
510
Range
2685 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
139 kts
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
139 kts
Distance
1063 m
