WW24
IAI 1124 Westwind
IAI 1124 Westwind
Aircraft
Name
1124 Westwind
Manufacturer
Body
Narrow
Wing
Fixed Wing
Position
Mid wing
Tail
Regular tail, mid set
WTC
M
APC
C
Type Code
L2J
Engine
Jet
Engine Count
Multi
Position
Both sides of rear fuselage
Manufactured as
IAI Sea Scan
IAI Westwind 1
IAI Westwind 2
IAI 1124 Sea Scan
IAI 1124 Westwind
IAI 1124 Westwind 1
IAI 1124 Westwind 2
IAI Westwind (1124)
WW24
Medium size corporate jet. First flight in 1976. More powerful turbofan development of IAI 1123 Westwind. In 1980, the basic IAI 1124 has been led to the 1124A Westwind 2 with improved performance, modified wing section and winglets. Production ceased in 1987 in favour of the IAI 1125 Astra.
Technical Data
Wing span (metric)
13.70 m
Length (metric)
15.90 m
Height (metric)
4.80 m
Powerplant
2 x 16.58 kN Garrett TFE731-3 turbofans.
Engine Model(s)
Garrett TFE731
Indicative Performance Data
Take-Off
V2
n/a
Distance
1200 m
MTOW
10660 kg
Initial Climb (to 5000 ft)
IAS
n/a
ROC
5000 ft/min
Initial Climb (to FL150)
IAS
n/a
ROC
n/a
Initial Climb (to FL240)
IAS
n/a
ROC
n/a
MACH Climb
MACH
n/a
ROC
n/a
Cruise
TAS
420 kts
MACH
0.74
Ceiling
450
Range
2400 NM
Initial Descent (to FL240)
MACH
n/a
ROD
n/a
Descent (to FL100)
IAS
n/a
ROD
n/a
Descent (FL100 & below)
IAS
n/a
MCS
n/a
ROD
n/a
Approach
Vapp (IAS)
n/a
Distance
560 m
