B741
BOEING 747-100
BOEING 747-100
Aircraft
Name
747-100
Manufacturer
Body
Wide
Wing
Fixed Wing
Position
Low wing
Tail
Regular tail, mid set
WTC
H
APC
D
Type Code
L4J
RFF Category
9
Engine
Jet
Engine Count
Multi
Position
Underwing mounted
Landing gear
Tricycle retractable
Manufactured as
BOEING 747-100
Cite This Page
SKYbrary Aviation Safety. (September 2, 2021). B741.
Retrieved June 4, 2026
from https://skybrary.aero/aircraft/b741
UID: 17647
Copied!
COPY
B741
Long range, high capacity wide-body airliner. In service since 1970. Initial model of first generation of 747 family. Last B747-100 was delivered in 1986. More than 200 747-100 were built. Approx. 140 remained in service in 1999, mainly as freighter.
The B741 is member of the B747 family of aircraft.
Technical Data
Wing span (metric)
59.60 m
Length (metric)
70.60 m
Height (metric)
19.30 m
Powerplant
4 x P&W JT9D-7A (209.9 kN) or
4 x P&W JT9D-7F (213.5 kN) or
4 x GE CF6-45A2 (206.8 kN) turbofans.
Engine Model(s)
General Electric CF6
Pratt & Whitney JT9D
Indicative Performance Data
Take-Off
V2
170 kts
Distance
3190 m
MTOW
333400 kg
Initial Climb (to 5000 ft)
IAS
200 kts
ROC
1000 ft/min
Initial Climb (to FL150)
IAS
290 kts
ROC
1500
Initial Climb (to FL240)
IAS
290 kts
ROC
1000 ft/min
MACH Climb
MACH
0.82
ROC
1000 ft/min
Cruise
TAS
500 kts
MACH
0.84
Ceiling
450
Range
5300 NM
Initial Descent (to FL240)
MACH
0.84
ROD
1000 ft/min
Descent (to FL100)
IAS
290 kts
ROD
3000 ft/min
Descent (FL100 & below)
IAS
n/a
MCS
240 kts
ROD
n/a
Approach
Vapp (IAS)
150 kts
Distance
1900 m
